Volume pricing
- 1+ pcs$18.47
- 10+ pcs$17.43
- 100+ pcs$16.44
- 500+ pcs$15.51
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Materials
- Beryllium Copper
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-On-On
- Contact Current Rating
- 100mA
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Mechanical Life
- 30,000 Cycles
- Terminal
- PC Pin
- Body Breadth
- 10.16 mm
- Montaj
- Through Hole
- Kurşunsuz
- Contains Lead
- Contact Plating
- Gold
- ECCN Kodu
- EAR99
- Contact Resistance
- 0.1mOhm
- Contact Finish
- Tin
- Pozisyon Sayısı
- 3
- Current Rating Amps
- 0.4VA AC/DC
- Fabrika Tedarik Süresi
- 11 Weeks
- Pcb Hole Count
- 10
- Uzunluk
- 10.7mm
- Max Voltage Rating Ac
- 28V
- Depth
- 10.7mm
- Voltage Rated Dc
- 28V
- Key Removable Positions
- All
- Yayın Yılı
- 2010
- Dielectric Withstanding Voltage
- 500VAC V
- Voltage Rated Ac
- 28V
- JESD-609 Kodu
- e4
- Body Height
- 10.4902mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Dc
- 28V
- Circuit
- SP3T
- Contact Timing
- Non-Shorting (BBM)
- Contact Style
- Non-Shorting
- Max Current Rating
- 100mA
- Özellikler
- Antistatic, Process Sealed
- Reach Svhc
- No SVHC
- Electricallife
- 20,000 Cycles
- Housing Material
- Polyester
- Switch Type
- KEYLOCK SWITCH
- Orientation
- Vertical
