Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- SPDT
- Montaj
- Panel
- Body Length Or Diameter
- 28.194mm
- Contact Resistance
- 0.015mOhm
- Length Termination
- 0.394 inch
- Seri
- SCB
- Terminal
- Quick Connect
- Housing Material
- THERMOPLASTIC
- JESD-609 Kodu
- e4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Breadth
- 13.9954 mm
- ECCN Kodu
- EAR99
- Mechanical Life
- 1,000,000 Cycles
- Contact Voltageacmax
- 250V
- Tip
- Standard
- Insulation Resistance
- 100000000Ohm
- Ambalaj
- Bulk
- Current Rating Amps
- 15A AC
- Yayın Yılı
- 2010
- Montaj Tipi
- Panel Mount, Rear
- Bushing Diameter
- 0.492 inch
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz Kodu
- yes
- Contact Function
- ON-(ON)
- REACH Uyumluluk Kodu
- not_compliant
- Actuator Type
- Round, Button
- Voltage Rated Ac
- 125V
- Bushing Length
- 0.394 inch
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Contact Current Rating
- 15A
- Switch Function
- On-Mom
- Parça Durumu
- Obsolete
- Contact Ac Max Rating R Load
- 15A@250VAC
- Fabrika Tedarik Süresi
- 8 Weeks
- Body Height
- 27.4066mm
- Color Actuatorcap
- Red
- Electricallife
- 50,000 Cycles
- Akım Değeri
- 15A
- Dielectric Withstanding Voltage
- 1500VAC V
- Contact Plating
- Silver
