Specifications
- Electricallife
- 10,000 Cycles
- Montaj
- Panel
- Kurşunsuz Kodu
- yes
- Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 2
- Color Actuatorcap
- Black
- Terminal
- Solder
- Max Voltage Rating Dc
- 30V
- Çalışma Sıcaklığı
- -10°C~70°C
- Depth
- 12mm
- Voltage Rated Dc
- 30V
- RoHS Durumu
- ROHS3 Compliant
- Current Rating Amps
- 3A AC 2A DC
- Akım Değeri
- 3A
- Contact Materials
- Silver
- Seri
- SB40
- Tip
- Standard
- Orientation
- Vertical
- Yayın Yılı
- 2007
- Ambalaj
- Bulk
- Housing Material
- Resin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- REACH Uyumluluk Kodu
- not_compliant
- Actuator Material
- Phenolic, Resin
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Uzunluk
- 12mm
- Illumination Type
- Illuminated
- Parça Durumu
- Active
- Max Voltage Rating Ac
- 250V
- Contact Current Rating
- 3A
- Number Of Poles
- 1
- Voltage Rated Ac
- 125V
- Mechanical Life
- 30,000 Cycles
- Montaj Tipi
- Panel Mount, Rear
- Özellikler
- Epoxy Sealed Terminals
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Switch Function
- Off-Mom
- Max Current Rating
- 3A
- Circuit
- SPST-NO
