Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Bushing Thread
- M12 x 1
- HTS Kodu
- 8536.50.90.65
- Parça Durumu
- Active
- Circuit
- 3PDT
- Voltage Rated Ac
- 125V
- Ambalaj
- Bulk
- Actuator Length
- 22.00mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Resistance
- 1000000000Ohm
- Illumination Type
- Illuminated, Non-Illuminated
- Max Current Rating
- 30A
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Dielectric Withstanding Voltage
- 2000VAC V
- Max Voltage Rating Dc
- 30V
- Kurşunsuz Kodu
- yes
- Contact Ac Max Rating R Load
- 30A@250VAC
- Çalışma Sıcaklığı
- -10°C~70°C
- Contact Resistance
- 0.01mOhm
- Montaj Tipi
- Panel Mount
- Contact Materials
- Silver
- Illumination
- Non-Illuminated
- Seri
- S
- Terminal
- Screw
- Uzunluk
- 42mm
- Contact Dc Max Rating R Load
- 30A@30VDC
- Max Voltage Rating Ac
- 250V
- Depth
- 43mm
- Body Height
- 34mm
- Actuator Type
- Standard Round
- Switch Function
- On-Off-On
- Orientation
- Vertical
- Bushing Type
- M12P1
- Current Rating Amps
- 30A AC/DC
- Terminal Stili
- Screw Terminal
- Contact Timing
- BREAK-BEFORE-MAKE
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Actuator Material
- Brass, Chrome Plated
- Electricallife
- 25,000 Cycles
