Specifications
- Seri
- S
- Illumination
- Non-Illuminated
- Terminal
- Screw
- Montaj Tipi
- Panel Mount
- Contact Resistance
- 0.01mOhm
- Çalışma Sıcaklığı
- -10°C~70°C
- Contact Ac Max Rating R Load
- 30A@250VAC
- Kurşunsuz Kodu
- yes
- Contact Voltageacmax
- 250V
- Dielectric Withstanding Voltage
- 2000VAC V
- Bushing Length
- 0.472 inch
- Actuator Length
- 22.00mm
- Ambalaj
- Bulk
- Voltage Rated Ac
- 125V
- Circuit
- DPDT
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Body Length Or Diameter
- 42.0116mm
- Insulation Resistance
- 1000000000Ohm
- Illumination Type
- Illuminated, Non-Illuminated
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Bushing Thread
- M12 x 1
- Contact Plating
- Nickel
- Fabrika Tedarik Süresi
- 18 Weeks
- Montaj
- Panel
- Akım Değeri
- 30A
- Voltage Rated Dc
- 30V
- Reach Svhc
- No SVHC
- Contact Current Rating
- 30A
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw Terminal
- Yayın Yılı
- 2012
- Electricallife
- 25,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Actuator Material
- Brass, Chrome Plated
- Body Breadth
- 24.003 mm
- Current Rating Amps
- 30A AC/DC
- Bushing Type
- M12P1
- REACH Uyumluluk Kodu
- unknown
- Switch Function
- On-Off-On
