Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 15A AC 20A DC
- Contact Function
- ON-OFF-(ON)
- Bushing Type
- M12P1
- Contact Ac Max Rating I Load
- 8A@125VAC
- Switch Function
- On-Off-Mom
- Actuator Type
- Flatted
- Depth
- 19mm
- Max Voltage Rating Ac
- 250V
- Voltage Rated Dc
- 30V
- Akım Değeri
- 20A
- Contact Currentacmax
- 6A
- Fabrika Tedarik Süresi
- 15 Weeks
- Montaj
- Panel
- RoHS Durumu
- ROHS3 Compliant
- Actuator Material
- Polybutylene Terephthalate (PBT)
- Electricallife
- 25,000 Cycles
- Body Breadth
- 18.9992 mm
- Contact Timing
- BREAK-BEFORE-MAKE
- Terminal Stili
- Solder Lug
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Max Current Rating
- 20A
- JESD-609 Kodu
- e3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Resistance
- 1000000000Ohm
- Ambalaj
- Bulk
- Voltage Rated Ac
- 125V
- Actuator Length
- 27.00mm
- Terminal Kaplaması
- Tin (Sn)
- Circuit
- DPDT
- Özellikler
- Black Actuator
- Bushing Thread
- M12 x 1
- Parça Durumu
- Active
- Uzunluk
- 33.2mm
- Switch Type
- TOGGLE SWITCH
- Contact Dc Max Rating R Load
- 20A@30VDC
- Terminal
- Solder
- Seri
- S300R
- Illumination
- Non-Illuminated
- Contact Materials
- Silver
- Contact Resistance
- 0.01mOhm
