Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 15A AC 20A DC
- Bushing Type
- M12P1
- Contact Ac Max Rating I Load
- 8A@125VAC
- Actuator Material
- Polybutylene Terephthalate (PBT)
- RoHS Durumu
- ROHS3 Compliant
- Body Breadth
- 18.9992 mm
- ECCN Kodu
- EAR99
- Terminal Stili
- Solder Lug
- Contact Current Rating
- 20A
- Montaj
- Panel
- Bushing Thread
- M12 x 1
- Parça Durumu
- Active
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Kaplaması
- Tin (Sn)
- Circuit
- DPDT
- Bushing Length
- 0.472 inch
- Contact Voltageacmax
- 250V
- Dielectric Withstanding Voltage
- 2000VAC V
- Contact Ac Max Rating R Load
- 6A@250VAC
- Switch Type
- TOGGLE SWITCH
- Illumination
- Non-Illuminated
- Switch Function
- Mom-Off-Mom
- Actuator Type
- Flatted
- Contact Function
- (ON)-OFF-(ON)
- Yayın Yılı
- 2012
- Electricallife
- 25,000 Cycles
- Voltage Rated Dc
- 30V
- Akım Değeri
- 20A
- Contact Currentacmax
- 6A
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 9 Weeks
- Contact Plating
- Silver
- Özellikler
- Black Actuator
- HTS Kodu
- 8536.50.90.40
- Kurşunsuz
- Lead Free
- Body Length Or Diameter
- 33.1978mm
- JESD-609 Kodu
- e3
- Illumination Type
- Illuminated, Non-Illuminated
- Insulation Resistance
- 1000000000Ohm
