Specifications
- Montaj
- Bushing, Panel
- Contact Current Rating
- 25A
- ECCN Kodu
- EAR99
- Terminal Stili
- Solder Lug
- Contact Timing
- BREAK-BEFORE-MAKE
- Actuator Material
- Brass, Chrome Plated
- RoHS Durumu
- ROHS3 Compliant
- Pin Sayısı
- 2
- Yükseklik
- 25.1mm
- Current Rating Amps
- 25A AC/DC
- Pozisyon Sayısı
- 3
- Depth
- 19mm
- Illumination
- Non-Illuminated
- Uzunluk
- 33.2mm
- Switch Type
- TOGGLE SWITCH
- Contact Materials
- Silver
- Terminal Kaplaması
- Tin (Sn)
- Circuit
- DPDT
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Max Current Rating
- 25A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Bushing Thread
- M12 x 1
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 9 Weeks
- Voltage Rated Dc
- 30V
- Akım Değeri
- 25A
- Contact Currentacmax
- 15A
- Reach Svhc
- No SVHC
- Electricallife
- 25,000 Cycles
- Max Voltage Rating Ac
- 250V
- Orientation
- Vertical
- Switch Function
- On-Off-On
- Actuator Type
- Standard Round
- Seri
- S300
- Terminal
- Solder
- Contact Resistance
- 0.01mOhm
- Montaj Tipi
- Panel Mount
- Max Voltage Rating Dc
- 30V
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -10°C~70°C
