Specifications
- Bushing Thread
- M12 x 1
- Parça Durumu
- Active
- Circuit
- 3PDT
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Max Current Rating
- 25A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 2000VAC V
- Contact Ac Max Rating R Load
- 9A@250VAC
- Contact Materials
- Silver
- Illumination
- Non-Illuminated
- Uzunluk
- 33.8mm
- Depth
- 30mm
- Contact Ac Max Rating I Load
- 10A@125VAC
- Current Rating Amps
- 20A AC/DC
- Pozisyon Sayısı
- 3
- Bushing Type
- M12P1
- ECCN Kodu
- EAR99
- Terminal Stili
- Solder Lug
- Contact Timing
- BREAK-BEFORE-MAKE
- Actuator Material
- Brass, Chrome Plated
- RoHS Durumu
- ROHS3 Compliant
- Body Breadth
- 29.9974 mm
- Montaj
- Panel
- Contact Current Rating
- 25A
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Voltage Rated Ac
- 125V
- Actuator Length
- 17.50mm
- JESD-609 Kodu
- e3
- Illumination Type
- Illuminated, Non-Illuminated
- Insulation Resistance
- 1000000000Ohm
- Contact Resistance
- 0.01mOhm
- Montaj Tipi
- Panel Mount
- Max Voltage Rating Dc
- 30V
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -10°C~70°C
- Additional Feature
- MEDIUM & HIGH RATED
- Seri
- S
- Terminal
- Solder
- Max Voltage Rating Ac
- 250V
