Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Bushing Thread
- M12 x 1
- Max Current Rating
- 25A
- Parça Durumu
- Active
- Max Voltage Rating Dc
- 30V
- Kurşunsuz Kodu
- yes
- Actuator Length
- 17.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Contact Ac Max Rating R Load
- 9A@250VAC
- Contact Materials
- Brass, Silver
- Kurşunsuz
- Lead Free
- Contact Dc Max Rating R Load
- 20A@30VDC
- Voltage Rated Dc
- 30V
- Reach Svhc
- No SVHC
- Dielectric Withstanding Voltage
- 2000VAC V
- Ambalaj
- Bulk
- Actuator Type
- Standard Round
- Contact Currentacmax
- 9A
- Akım Değeri
- 20A
- RoHS Durumu
- ROHS3 Compliant
- Insulation Resistance
- 1000000000Ohm
- Montaj
- Bushing, Panel
- Circuit
- 3PST
- Bushing Type
- M12P1
- Contact Ac Max Rating I Load
- 10A@125VAC
- Current Rating Amps
- 20A AC/DC
- Fabrika Tedarik Süresi
- 5 Weeks
- Contact Resistance
- 0.01mOhm
- Max Voltage Rating Ac
- 250V
- Illumination
- Non-Illuminated
- Montaj Tipi
- Panel Mount
- Actuator Material
- Brass, Chrome Plated
- Terminal
- Solder
- Body Breadth
- 29.9974 mm
- Switch Function
- On-Off
- Contact Current Rating
- 25A
- Voltage Rated Ac
- 125V
- Additional Feature
- MEDIUM & HIGH RATED
- JESD-609 Kodu
- e3
- ECCN Kodu
- EAR99
