Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuator Length
- 17.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Illumination
- Non-Illuminated
- Bushing Thread
- M12 x 1
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Actuator Material
- Brass, Chrome Plated
- Terminal Kaplaması
- Tin (Sn)
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Contact Ac Max Rating R Load
- 6A@250VAC
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Panel Mount
- Voltage Rated Dc
- 30V
- Body Length Or Diameter
- 28.4988mm
- Switch Function
- On-On
- Contact Voltageacmax
- 250V
- Dielectric Withstanding Voltage
- 2000VAC V
- Reach Svhc
- No SVHC
- Yayın Yılı
- 2012
- Terminal
- Quick Connect
- Bushing Length
- 0.472 inch
- Body Breadth
- 16.002 mm
- Additional Feature
- HIGH RATED
- JESD-609 Kodu
- e3
- Ambalaj
- Bulk
- Contact Current Rating
- 20A
- Voltage Rated Ac
- 125V
- ECCN Kodu
- EAR99
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Montaj
- Bushing, Panel
- Switch Type
- TOGGLE SWITCH
- Actuator Type
- Standard Round
- Contact Currentacmax
- 6A
- Akım Değeri
- 20A
- RoHS Durumu
- ROHS3 Compliant
- Insulation Resistance
- 1000000000Ohm
- Contact Ac Max Rating I Load
- 10A@125VAC
- Current Rating Amps
- 15A AC 20A DC
- Contact Plating
- Silver
- Illumination Type
- Illuminated, Non-Illuminated
