Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Dielectric Withstanding Voltage
- 2000VAC V
- Reach Svhc
- No SVHC
- Voltage Rated Dc
- 30V
- Contact Dc Max Rating R Load
- 20A@30VDC
- Terminal Kaplaması
- Tin (Sn)
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Contact Ac Max Rating R Load
- 6A@250VAC
- Contact Materials
- Copper
- Kurşunsuz
- Lead Free
- Actuator Length
- 17.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 20A
- Bushing Thread
- M12 x 1
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Dc
- 30V
- Contact Resistance
- 0.01mOhm
- Fabrika Tedarik Süresi
- 9 Weeks
- Contact Ac Max Rating I Load
- 10A@125VAC
- Current Rating Amps
- 15A AC 20A DC
- Circuit
- SPDT
- Bushing Type
- M12P1
- Montaj
- Panel
- Actuator Type
- Standard Round
- Contact Currentacmax
- 6A
- RoHS Durumu
- ROHS3 Compliant
- Akım Değeri
- 20A
- Insulation Resistance
- 1GOhm
- Ambalaj
- Bulk
- Switch Function
- On-On
- Terminal
- Solder
- Body Breadth
- 16.002 mm
- Actuator Material
- Brass, Chrome Plated
- Montaj Tipi
- Panel Mount
- Max Voltage Rating Ac
- 250V
- Illumination
- Non-Illuminated
- Yükseklik
- 17.4mm
- Seri
- S300
- Çalışma Sıcaklığı
- -10°C~70°C
- Uzunluk
- 28.5mm
