Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Illumination
- Non-Illuminated
- Max Voltage Rating Ac
- 250V
- Contact Timing
- BREAK-BEFORE-MAKE
- Montaj Tipi
- Panel Mount
- Actuator Material
- Brass, Chrome Plated
- Onay Kuruluşu
- CSA, UL
- Body Breadth
- 16.002 mm
- Terminal
- Solder
- Switch Function
- On-Off
- Voltage Rated Ac
- 125V
- Contact Current Rating
- 20A
- JESD-609 Kodu
- e3
- Additional Feature
- HIGH RATED
- Switch Type
- TOGGLE SWITCH
- ECCN Kodu
- EAR99
- Terminal Stili
- Solder Lug
- Orientation
- Vertical
- Depth
- 16mm
- Illumination Type
- Illuminated, Non-Illuminated
- Electricallife
- 25,000 Cycles
- HTS Kodu
- 8536.50.90.65
- Uzunluk
- 28.5mm
- Çalışma Sıcaklığı
- -10°C~70°C
- Seri
- S300
- Max Current Rating
- 20A
- Bushing Thread
- M12 x 1
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Dc
- 30V
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Length
- 17.50mm
- Contact Ac Max Rating R Load
- 6A@250VAC
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Terminal Kaplaması
- Tin (Sn)
- Kurşunsuz
- Lead Free
- Contact Materials
- Silver
- Contact Dc Max Rating R Load
- 20A@30VDC
- Voltage Rated Dc
- 30V
- Reach Svhc
- No SVHC
- Dielectric Withstanding Voltage
- 2000VAC V
