Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Currentacmax
- 6A
- Illumination
- Non-Illuminated
- Body Height
- 18.0086mm
- Bushing Type
- M12P1
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2012
- Bushing Thread
- M12 x 1
- Voltage Rated Ac
- 125V
- Akım Değeri
- 20A
- Uzunluk
- 30mm
- Current Rating Amps
- 15A AC 20A DC
- Contact Resistance
- 0.01mOhm
- Kurşunsuz Kodu
- yes
- Actuator Material
- Brass, Chrome Plated
- Depth
- 18mm
- Max Current Rating
- 20A
- Contact Dc Max Rating R Load
- 20A@30VDC
- RoHS Durumu
- ROHS3 Compliant
- Actuator Length
- 17.50mm
- Contact Materials
- Silver
- Dielectric Withstanding Voltage
- 2000VAC V
- Terminal
- Quick Connect
- Contact Ac Max Rating R Load
- 6A@250VAC
- Ratings
- Dust Tight, IP67, Waterproof
- Fabrika Tedarik Süresi
- 9 Weeks
- Reach Svhc
- No SVHC
- Insulation Resistance
- 1000000000Ohm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Ac
- 250V
- Çalışma Sıcaklığı
- -30°C~70°C
- ECCN Kodu
- EAR99
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- JESD-609 Kodu
- e3
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Body Breadth
- 18.0086 mm
- Actuator Type
- Standard Round
- Switch Function
- On-On
- Parça Durumu
- Active
- Seri
- S
