Specifications
- Dielectric Withstanding Voltage
- 2000VAC V
- Montaj Tipi
- Panel Mount
- Contact Ac Max Rating R Load
- 5A@250VAC
- Ambalaj
- Bulk
- Terminal
- Solder
- Actuator Length
- 17.50mm
- Contact Materials
- Silver
- Additional Feature
- MEDIUM RATED
- Contact Currentdcmax
- 10A
- Contact Ac Max Rating I Load
- 5A@125VAC
- Illumination Type
- Illuminated, Non-Illuminated
- Montaj
- Panel
- HTS Kodu
- 8536.50.90.65
- Circuit
- DPST
- Seri
- S
- Parça Durumu
- Obsolete
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.01mOhm
- Current Rating Amps
- 5A AC/DC
- Switch Function
- On-Off
- Actuator Type
- Standard Round
- Contact Timing
- BREAK-BEFORE-MAKE
- RoHS Durumu
- RoHS Compliant
- Electricallife
- 25,000 Cycles
- Actuator Material
- Brass, Chrome Plated
- Yayın Yılı
- 2012
- Voltage Rated Dc
- 30V
- ECCN Kodu
- EAR99
- Bushing Thread
- M12 x 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Length Or Diameter
- 31.1912mm
- Çalışma Sıcaklığı
- -10°C~70°C
- Akım Değeri
- 5A
- Voltage Rated Ac
- 125V
- Terminal Stili
- Solder Lug
- Body Breadth
- 18.5928 mm
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- JESD-609 Kodu
- e3
- Throw Configuration
- DPST, SPST
