Volume pricing
- 1+ pcs$8.79
- 10+ pcs$8.29
- 100+ pcs$7.82
- 500+ pcs$7.38
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 28V
- Actuator Travel
- 0.9906 mm
- Ambalaj
- Bulk
- Actuator Material
- BRASS
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Fabrika Tedarik Süresi
- 9 Weeks
- Montaj
- Panel
- Çalışma Sıcaklığı
- -30°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2014
- Parça Durumu
- Active
- Actuator Finish
- NICKEL
- Terminal
- PC Pin
- Body Height
- 10.3124mm
- Voltage Rated Ac
- 28V
- ECCN Kodu
- EAR99
- Contact Resistance
- 0.03mOhm
- Center Contact Plating
- GOLD
- Switch Function
- On-Mom
- Circuit
- SPDT
- Insulation Materials
- DIALLYL PHTHALATE
- Electricallife
- 100,000 Cycles
- Center Contact Material
- COPPER
- RoHS Durumu
- ROHS3 Compliant
- Flammability Rating
- UL94 V-0
- Mechanical Life
- 200,000 Cycles
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Pcb Hole Count
- 3
- Insulation Resistance
- 1000000000Ohm
- Kurşunsuz Kodu
- yes
- Length Termination
- 0.25 inch
- Tip
- Standard
- Body Length Or Diameter
- 13.0048mm
- Bushing Length
- 0.315 inch
- Seri
- MB2500
- Actuator Type
- Round, Button
- Body Breadth
- 7.8994 mm
- Contact Function
- ON-(ON)
- Housing Material
- STAINLESS STEEL
- Contact Timing
- SNAP ACTION
