Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Plating
- Gold
- Montaj Tipi
- Panel Mount, Rear
- Terminal Stili
- Solder Lug
- Current Rating Amps
- 0.4VA AC/DC
- Özellikler
- Epoxy Sealed Terminals
- Uzunluk
- 13mm
- Illumination Type
- Illuminated
- Seri
- MB2500
- Actuator Type
- Plunger for Cap
- Max Current Rating
- 100mA
- Tip
- Standard
- Housing Material
- Resin
- Additional Feature
- CAP COLOUR- BLACK
- Contact Function
- ON-(ON)
- Body Breadth
- 7.8994 mm
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Insulation Resistance
- 1000000000Ohm
- Depth
- 7.9mm
- Kurşunsuz Kodu
- yes
- Circuit
- SPDT
- Max Voltage Rating Dc
- 28V
- Electricallife
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Mechanical Life
- 200,000 Cycles
- Voltage Rated Ac
- 28V
- Power Rating
- 400mW
- Contact Resistance
- 0.03mOhm
- ECCN Kodu
- EAR99
- Switch Function
- On-Mom
- Çalışma Sıcaklığı
- -30°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Yayın Yılı
- 2014
- Max Voltage Rating Ac
- 28V
- Body Height
- 10.3124mm
- Actuator Finish
- NICKEL
- Terminal
- Solder
- Contact Materials
- Copper
- Voltage Rated Dc
- 28V
- Ambalaj
- Bulk
