Specifications
- Illumination Type
- Illuminated
- Color Actuatorcap
- Red
- Kurşunsuz
- Contains Lead
- Current Rating Amps
- 3A AC
- Terminal Stili
- Solder Lug
- JESD-609 Kodu
- e4
- Panel Cutout Dimensions
- Rectangular - 15.00mm x 12.50mm
- Akım Değeri
- 3A
- Max Current Rating
- 3A
- Tip
- Standard
- Seri
- MB2400
- Body Breadth
- 7.8994 mm
- Additional Feature
- BLACK BEZEL
- ECCN Kodu
- EAR99
- Circuit
- SPDT
- Electricallife
- 25,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Flammability Rating
- UL94 V-0
- Mechanical Life
- 200,000 Cycles
- Number Of Poles
- 1
- Max Voltage Rating Ac
- 125V
- Contact Materials
- Silver
- Terminal
- Solder
- Özellikler
- Epoxy Sealed Terminals
- Uzunluk
- 21.5mm
- Orientation
- Vertical
- Montaj Tipi
- Panel Mount, Snap-In
- Terminal Material
- COPPER ALLOY
- Depth
- 15.6mm
- Insulation Resistance
- 1GOhm
- Kurşunsuz Kodu
- yes
- Actuator Type
- Square, Button
- Contact Function
- ON-(ON)
- Housing Material
- Resin
- Voltage Rated Ac
- 125V
- Switch Function
- On-Mom
- REACH Uyumluluk Kodu
- not_compliant
- Contact Currentacmax
- 3A
- Contact Current Rating
- 3A
- Solderability
- WAVE
