Volume pricing
- 1+ pcs$8.38
- 10+ pcs$7.91
- 100+ pcs$7.46
- 500+ pcs$7.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Body Breadth
- 8.001 mm
- Contact Function
- ON-(ON)
- Dielectric Withstanding Voltage
- 1500VAC V
- Housing Material
- Resin
- Tip
- Standard
- Max Current Rating
- 100mA
- Actuator Type
- Plunger for Cap
- Seri
- MB2400
- Kurşunsuz Kodu
- yes
- Pcb Hole Count
- 7
- Depth
- 8mm
- Insulation Resistance
- 1000000000Ohm
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Current Rating Amps
- 0.4VA AC/DC
- Terminal Stili
- PC Pin
- JESD-609 Kodu
- e4
- Montaj Tipi
- Panel Mount, Rear
- Kurşunsuz
- Lead Free
- Orientation
- Vertical
- Contact Plating
- Gold
- Uzunluk
- 16.3mm
- Özellikler
- Epoxy Sealed Terminals
- Contact Materials
- Copper
- Terminal
- PC Pin
- Actuator Finish
- NICKEL
- Body Height
- 29.083mm
- Max Voltage Rating Ac
- 28V
- Yayın Yılı
- 2012
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -30°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Panel
- Fabrika Tedarik Süresi
- 5 Weeks
- Solderability
- WAVE
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Actuator Material
- Brass
- Ambalaj
- Bulk
- Voltage Rated Dc
- 28V
- Mechanical Life
- 200,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
