Volume pricing
- 1+ pcs$9.71
- 10+ pcs$9.16
- 100+ pcs$8.64
- 500+ pcs$8.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Center Contact Plating
- SILVER
- Body Length Or Diameter
- 13.0048mm
- Özellikler
- Epoxy Sealed Terminals
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 5 Weeks
- Montaj Tipi
- Panel Mount, Rear
- Body Height
- 46.3296mm
- Tip
- Standard
- Color Actuatorcap
- Black
- Contact Currentacmax
- 3A
- Contact Voltageacmax
- 250V
- Voltage Rated Dc
- 30V
- Switch Function
- On-On
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.01mOhm
- End Contact Plating
- SILVER
- Montaj
- Panel
- Actuator Material
- POLYSTYRENE
- Kurşunsuz
- Contains Lead
- Insulation Materials
- DIALLYL PHTHALATE
- End Contact Material
- SILVER
- Terminal Material
- COPPER ALLOY
- Body Breadth
- 7.8994 mm
- Contact Ac Max Rating R Load
- 3A@250VAC
- Seri
- MB2000
- Voltage Rated Ac
- 125V
- Actuator Travel
- 3.8862 mm
- Orientation
- Vertical
- Yayın Yılı
- 2012
- Electricallife
- 25,000 Cycles
- Length Termination
- 0.25 inch
- Ambalaj
- Bulk
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Bushing Diameter
- 0.472 inch
- Çalışma Sıcaklığı
- -30°C~85°C
- Terminal Kaplaması
- GOLD OVER NICKEL/SILVER
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Contact Timing
- SLOW-MAKE/-BREAK
- Insulation Resistance
- 1000000000Ohm
