Specifications
- Çalışma Sıcaklığı
- -30°C~85°C
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC 3A DC
- Terminal Stili
- Solder Lug
- Yayın Yılı
- 2006
- Electricallife
- 25,000 Cycles
- Actuator Finish
- NICKEL
- Orientation
- Vertical
- Length Termination
- 0.157 inch
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Actuator Length
- 0.41 inch
- Akım Değeri
- 3A
- Terminal
- Solder
- Actuator Type
- Round, Button
- ECCN Kodu
- EAR99
- Dielectric Withstanding Voltage
- 1500VAC V
- Housing Material
- Resin
- Bushing Length
- 0.335 inch
- REACH Uyumluluk Kodu
- not_compliant
- Color Actuatorcap
- Black
- Tip
- Standard
- Contact Currentacmax
- 3A
- Contact Voltageacmax
- 250V
- Switch Function
- On-On
- Voltage Rated Dc
- 30V
- Contact Plating
- Silver
- Özellikler
- Epoxy Sealed Terminals
- Fabrika Tedarik Süresi
- 5 Weeks
- Circuit
- SPDT
- Body Length Or Diameter
- 13.0048mm
- Body Height
- 41.2242mm
- Montaj Tipi
- Panel Mount, Rear
- Contact Current Rating
- 6A
- Body Breadth
- 7.8994 mm
- Contact Ac Max Rating R Load
- 3A@250VAC
