Specifications
- REACH Uyumluluk Kodu
- not_compliant
- Housing Material
- STAINLESS STEEL
- Max Current Rating
- 6A
- ECCN Kodu
- EAR99
- Dielectric Withstanding Voltage
- 1500VAC V
- Depth
- 12.7mm
- Akım Değeri
- 3A
- Terminal
- Solder
- Actuator Type
- Round, Button
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Ambalaj
- Bulk
- Yayın Yılı
- 2011
- Electricallife
- 25,000 Cycles
- Actuator Finish
- NICKEL
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC 3A DC
- Terminal Stili
- Solder Lug
- Bushing Diameter
- 0.25 inch
- Çalışma Sıcaklığı
- -30°C~85°C
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Panel
- Actuator Material
- Brass
- Kurşunsuz
- Lead Free
- Insulation Materials
- DIALLYL PHTHALATE
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.01mOhm
- Contact Materials
- Silver
- Max Voltage Rating Dc
- 30V
- Contact Ac Max Rating R Load
- 3A@250VAC
- Seri
- MB2000
- Contact Function
- ON-(ON)
- Voltage Rated Ac
- 125V
- Contact Current Rating
- 6A
- Fabrika Tedarik Süresi
- 5 Weeks
- Circuit
- DPDT
- Özellikler
- Epoxy Sealed Terminals
- Montaj Tipi
- Panel Mount, Rear
