Specifications
- Body Height
- 46.3296mm
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Montaj Tipi
- Panel Mount, Rear
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 5 Weeks
- Circuit
- DPDT
- Özellikler
- Epoxy Sealed Terminals
- Body Length Or Diameter
- 13.0048mm
- Contact Plating
- Silver
- Illumination Type
- Illuminated
- Switch Function
- On-Mom
- Voltage Rated Dc
- 30V
- Contact Voltageacmax
- 250V
- Tip
- Standard
- Pcb Hole Count
- 6
- Color Actuatorcap
- Black
- Contact Currentacmax
- 3A
- Actuator Material
- POLYSTYRENE
- Montaj
- Panel
- Ratings
- Dust Tight, IP67, Waterproof
- Contact Resistance
- 0.01mOhm
- Kurşunsuz Kodu
- yes
- Actuator Travel
- 1.8034 mm
- Contact Function
- ON-(ON)
- Seri
- MB2000
- Flammability Rating
- UL94 V-0
- Voltage Rated Ac
- 125V
- Contact Ac Max Rating R Load
- 3A@250VAC
- Terminal Material
- COPPER ALLOY
- Body Breadth
- 12.7 mm
- Contact Current Rating
- 6A
- Additional Feature
- SPLASH-PROOF BUSHING
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Ambalaj
- Bulk
- Length Termination
- 0.25 inch
- Yayın Yılı
- 2012
- Electricallife
- 25,000 Cycles
- Terminal Stili
- PC Pin
- Current Rating Amps
- 6A AC 3A DC
- Insulation Resistance
- 1000000000Ohm
