Volume pricing
- 1+ pcs$9.49
- 10+ pcs$8.95
- 100+ pcs$8.44
- 500+ pcs$7.96
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Currentacmax
- 3A
- Color Actuatorcap
- Black
- Tip
- Standard
- Contact Voltageacmax
- 250V
- Switch Function
- On-Mom
- Voltage Rated Dc
- 30V
- Contact Plating
- Silver
- Özellikler
- Epoxy Sealed Terminals
- Circuit
- DPDT
- Fabrika Tedarik Süresi
- 5 Weeks
- Body Length Or Diameter
- 13.0048mm
- Body Height
- 42.2656mm
- Montaj Tipi
- Panel Mount, Rear
- Body Breadth
- 12.7 mm
- Terminal Material
- COPPER ALLOY
- Contact Ac Max Rating R Load
- 3A@250VAC
- Actuator Travel
- 1.8034 mm
- Flammability Rating
- UL94 V-0
- Voltage Rated Ac
- 125V
- Seri
- MB2000
- Contact Function
- ON-(ON)
- Contact Resistance
- 0.01mOhm
- Kurşunsuz Kodu
- yes
- Montaj
- Panel
- Kurşunsuz
- Lead Free
- Actuator Material
- POLYSTYRENE
- Çalışma Sıcaklığı
- -30°C~85°C
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC 3A DC
- Terminal Stili
- Solder Lug
- Electricallife
- 25,000 Cycles
- Yayın Yılı
- 2012
- Orientation
- Vertical
- Length Termination
- 0.157 inch
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Ambalaj
- Bulk
- JESD-609 Kodu
- e4
- Parça Durumu
- Active
