Volume pricing
- 1+ pcs$12.30
- 10+ pcs$11.60
- 100+ pcs$10.94
- 500+ pcs$10.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Housing Material
- Resin
- REACH Uyumluluk Kodu
- not_compliant
- Actuator Material
- Polyacetal
- Montaj
- Panel
- Max Voltage Rating Dc
- 28V
- Dielectric Withstanding Voltage
- 1500VAC V
- Contact Resistance
- 0.02mOhm
- Contact Materials
- Copper
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Max Current Rating
- 100mA
- Power Rating
- 400mW
- Flammability Rating
- UL94 V-0
- Actuator Type
- Round, Button
- Terminal
- Solder
- Voltage Rated Ac
- 28V
- Contact Function
- ON-(ON)
- Seri
- MB2000
- Depth
- 13.2mm
- Body Breadth
- 12.7 mm
- Parça Durumu
- Active
- Solderability
- WAVE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e4
- Max Voltage Rating Ac
- 28V
- Body Height
- 43.9674mm
- Montaj Tipi
- Panel Mount, Rear
- Özellikler
- Epoxy Sealed Terminals
- Fabrika Tedarik Süresi
- 8 Weeks
- Circuit
- DPDT
- Ambalaj
- Bulk
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Electricallife
- 50,000 Cycles
- Yayın Yılı
- 2012
- Contact Plating
- Gold
- Switch Function
- On-Mom
- Terminal Stili
- Solder Lug
- Voltage Rated Dc
- 28V
- Uzunluk
- 13.2mm
