Specifications
- Terminal
- PC Pin
- Actuator Type
- Round, Button
- Akım Değeri
- 3A
- Depth
- 12.7mm
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Solderability
- WAVE
- Housing Material
- Resin
- REACH Uyumluluk Kodu
- not_compliant
- Dielectric Withstanding Voltage
- 1500VAC V
- ECCN Kodu
- EAR99
- Max Current Rating
- 6A
- Terminal Stili
- PC Pin
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC 3A DC
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Contact Timing
- SLOW-MAKE/-BREAK
- Çalışma Sıcaklığı
- -30°C~85°C
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Ambalaj
- Bulk
- Electricallife
- 25,000 Cycles
- Yayın Yılı
- 2006
- Flammability Rating
- UL94 V-0
- Voltage Rated Ac
- 125V
- Seri
- MB2000
- Contact Function
- ON-(ON)
- Contact Ac Max Rating R Load
- 3A@250VAC
- Terminal Material
- COPPER ALLOY
- Kurşunsuz
- Lead Free
- Actuator Material
- Brass
- Montaj
- Panel
- Max Voltage Rating Dc
- 30V
- Contact Resistance
- 0.01mOhm
- Contact Materials
- Silver
- Kurşunsuz Kodu
- yes
- Switch Function
- On-Mom
- Voltage Rated Dc
- 30V
- Uzunluk
- 13mm
- Contact Currentacmax
- 3A
