Specifications
- Contact Plating
- Gold
- Reach Svhc
- No SVHC
- Montaj Tipi
- Panel Mount, Rear
- Max Voltage Rating Ac
- 250V
- Body Height
- 38.8366mm
- Fabrika Tedarik Süresi
- 8 Weeks
- Circuit
- SPDT
- Özellikler
- Epoxy Sealed Terminals
- Contact Currentacmax
- 6A
- Color Actuatorcap
- Black
- Tip
- Standard
- Voltage Rated Dc
- 30V
- Switch Function
- On-Mom
- Uzunluk
- 13mm
- Max Voltage Rating Dc
- 30V
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.02mOhm
- Contact Materials
- Silver
- Actuator Material
- Brass
- Montaj
- Panel
- Body Breadth
- 7.8994 mm
- Contact Current Rating
- 6A
- Flammability Rating
- UL94 V-0
- Voltage Rated Ac
- 125V
- Seri
- MB2000
- Contact Function
- ON-(ON)
- Contact Ac Max Rating R Load
- 6A@125VAC
- Electricallife
- 25,000 Cycles
- Actuator Finish
- NICKEL
- Yayın Yılı
- 2011
- Ambalaj
- Bulk
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Mechanical Life
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Çalışma Sıcaklığı
- -30°C~85°C
- Terminal Stili
- Solder Lug
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC 3A DC
- Dielectric Withstanding Voltage
- 1500VAC V
- Max Current Rating
- 6A
