Specifications
- Dielectric Withstanding Voltage
- 1500VAC V
- ECCN Kodu
- EAR99
- REACH Uyumluluk Kodu
- not_compliant
- Housing Material
- Resin
- Bushing Length
- 0.472 inch
- Solderability
- WAVE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- JESD-609 Kodu
- e4
- Terminal
- PC Pin
- Actuator Type
- Round, Button
- Power Rating
- 400mW
- Actuator Length
- 0.523 inch
- Length Termination
- 0.25 inch
- Orientation
- Vertical
- Yayın Yılı
- 2012
- Electricallife
- 50,000 Cycles
- Ambalaj
- Bulk
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- RoHS Durumu
- ROHS3 Compliant
- Mechanical Life
- 50,000 Cycles
- Çalışma Sıcaklığı
- -30°C~85°C
- Terminal Stili
- PC Pin
- Current Rating Amps
- 0.4VA AC/DC
- Insulation Resistance
- 1000000000Ohm
- Ratings
- Dust Tight, IP67, Waterproof
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.02mOhm
- Actuator Material
- POLYSTYRENE
- Kurşunsuz
- Lead Free
- Montaj
- Panel
- Terminal Material
- COPPER ALLOY
- Body Breadth
- 7.8994 mm
- Additional Feature
- SPLASH-PROOF BUSHING
- End Contact Material
- COPPER ALLOY
- Contact Function
- ON-(ON)
- Seri
- MB2000
- Voltage Rated Ac
- 28V
- Flammability Rating
- UL94 V-0
- Actuator Travel
- 1.8034 mm
