Volume pricing
- 1+ pcs$10.85
- 10+ pcs$10.24
- 100+ pcs$9.66
- 500+ pcs$9.11
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuator Material
- POLYSTYRENE
- Montaj
- Panel
- Ratings
- Dust Tight, IP67, Waterproof
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.02mOhm
- Flammability Rating
- UL94 V-0
- Voltage Rated Ac
- 28V
- Seri
- MB2000
- Contact Function
- ON-(ON)
- Actuator Travel
- 1.8034 mm
- Body Breadth
- 7.8994 mm
- Terminal Material
- COPPER ALLOY
- Additional Feature
- SPLASH-PROOF BUSHING
- End Contact Material
- COPPER ALLOY
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Montaj Tipi
- Panel Mount, Rear
- Body Height
- 40.9702mm
- Body Length Or Diameter
- 13.0048mm
- Fabrika Tedarik Süresi
- 8 Weeks
- Circuit
- SPDT
- Özellikler
- Epoxy Sealed Terminals
- Contact Plating
- Gold
- Voltage Rated Dc
- 28V
- Switch Function
- On-Mom
- Color Actuatorcap
- Red
- Tip
- Standard
- REACH Uyumluluk Kodu
- not_compliant
- Bushing Length
- 0.472 inch
- Housing Material
- Resin
- Dielectric Withstanding Voltage
- 1500VAC V
- ECCN Kodu
- EAR99
- Actuator Type
- Round, Button
- Terminal
- Solder
- Power Rating
- 400mW
- Actuator Length
- 0.472 inch
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Solderability
- WAVE
- JESD-609 Kodu
- e4
- Ambalaj
- Bulk
