Specifications
- Length Termination
- 0.157 inch
- Orientation
- Vertical
- Yayın Yılı
- 2012
- Electricallife
- 25,000 Cycles
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Ambalaj
- Bulk
- Mechanical Life
- 100,000 Cycles
- Contact Timing
- SLOW-MAKE/-BREAK
- RoHS Durumu
- ROHS3 Compliant
- Bushing Diameter
- 0.472 inch
- Çalışma Sıcaklığı
- -30°C~85°C
- Terminal Stili
- Solder Lug
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC 3A DC
- Dielectric Withstanding Voltage
- 1500VAC V
- ECCN Kodu
- EAR99
- REACH Uyumluluk Kodu
- not_compliant
- Housing Material
- STAINLESS STEEL
- Bushing Length
- 0.472 inch
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Solderability
- WAVE
- Parça Durumu
- Active
- JESD-609 Kodu
- e4
- Actuator Type
- Round, Button
- Terminal
- Solder
- Actuator Length
- 0.523 inch
- Akım Değeri
- 3A
- Montaj Tipi
- Panel Mount, Rear
- Body Height
- 42.2656mm
- Body Length Or Diameter
- 13.0048mm
- Fabrika Tedarik Süresi
- 5 Weeks
- Circuit
- SPDT
- Özellikler
- Epoxy Sealed Terminals
- Color Actuatorcap
- Red
- Tip
- Standard
- Contact Currentacmax
- 3A
- Voltage Rated Dc
- 30V
- Switch Function
- On-Mom
- Contact Voltageacmax
- 250V
- Kurşunsuz Kodu
- yes
