Volume pricing
- 1+ pcs$7.51
- 10+ pcs$7.09
- 100+ pcs$6.68
- 500+ pcs$6.31
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz Kodu
- yes
- Actuator Length
- 7.62mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Parça Durumu
- Obsolete
- Body Length Or Diameter
- 15.748mm
- Center Contact Plating
- GOLD OVER NICKEL
- Kurşunsuz
- Contains Lead
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Bushing Thread
- Unthreaded
- Voltage Rated Dc
- 28V
- Center Contact Material
- COPPER ALLOY
- Akım Değeri
- 100mA
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Washability
- SOLVENT
- Solderability
- WAVE
- Contact Resistance
- 0.02mOhm
- Actuator Type
- Standard Round
- End Contact Plating
- GOLD OVER NICKEL
- Terminal
- PC Pin
- Yayın Yılı
- 2010
- Circuit
- DPDT
- Power Rating
- 400mW
- Illumination
- Non-Illuminated
- Contact Function
- (ON)-OFF-(ON)
- Length Termination
- 0.185 inch
- Terminal Material
- COPPER ALLOY
- Özellikler
- Process Sealed
- Seri
- M2
- Life Cycles
- 50000 cycles
- Dielectric Withstanding Voltage
- 1500VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- End Contact Material
- COPPER ALLOY
- Ambalaj
- Tray
- Current Rating Amps
- 0.4VA AC/DC
- Switch Function
- Mom-Off-Mom
- Actuator Material
- Brass, Chrome Plated
- Insulation Resistance
- 1000000000Ohm
- REACH Uyumluluk Kodu
- not_compliant
- Switch Type
- TOGGLE SWITCH
