Specifications
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Çalışma Sıcaklığı
- -30°C~85°C
- Parça Durumu
- Obsolete
- Body Length Or Diameter
- 12.7mm
- Kurşunsuz Kodu
- yes
- Actuator Length
- 7.62mm
- Contact Currentacmax
- 6A
- Illumination Type
- Illuminated, Non-Illuminated
- Bushing Thread
- Unthreaded
- Contact Resistance
- 0.02mOhm
- Actuator Type
- Standard Round
- Washability
- SOLVENT
- Kılıf / Paket
- 300
- Contact Plating
- Gold, Silver
- Solderability
- WAVE
- Akım Değeri
- 4A
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Voltage Rated Dc
- 30V
- Illumination
- Non-Illuminated
- Power Rating
- 400mW
- Circuit
- DPDT
- Terminal
- PC Pin
- Yayın Yılı
- 2012
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Process Sealed
- Seri
- M2
- Dielectric Withstanding Voltage
- 1500VAC V
- Length Termination
- 0.146 inch
- Terminal Material
- COPPER ALLOY
- Current Rating Amps
- 6A AC 4A DC
- Contact Ac Max Rating R Load
- 6A@125VAC
- Switch Function
- On-On
- Actuator Material
- Brass, Chrome Plated
- Insulation Resistance
- 1000000000Ohm
- Ambalaj
- Bulk
- Bushing Length
- 0.25 inch
- Sealing
- EPOXY
- Montaj Tipi
- Through Hole, Right Angle
- Switch Type
- TOGGLE SWITCH
