Specifications
- Parça Durumu
- Obsolete
- Çalışma Sıcaklığı
- -30°C~85°C
- Body Length Or Diameter
- 15.748mm
- Kurşunsuz Kodu
- yes
- Actuator Length
- 12.70mm
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Contact Currentacmax
- 3A
- Bushing Thread
- Unthreaded
- Illumination Type
- Illuminated, Non-Illuminated
- Akım Değeri
- 3A
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Voltage Rated Dc
- 30V
- Contact Resistance
- 0.01mOhm
- Actuator Type
- Standard Round
- Washability
- SOLVENT
- Contact Plating
- Silver
- Solderability
- WAVE
- Circuit
- SPDT
- Terminal
- PC Pin
- Yayın Yılı
- 2012
- Illumination
- Non-Illuminated
- Length Termination
- 0.185 inch
- Terminal Material
- COPPER ALLOY
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Process Sealed
- Contact Voltageacmax
- 250V
- Seri
- M2
- Dielectric Withstanding Voltage
- 1500VAC V
- Ambalaj
- Bulk
- Contact Ac Max Rating R Load
- 3A@250VAC
- Current Rating Amps
- 6A AC 3A DC
- Switch Function
- On-Off-On
- Actuator Material
- Brass, Chrome Plated
- Insulation Resistance
- 1000000000Ohm
- Switch Type
- TOGGLE SWITCH
- Terminal Stili
- PC Pin
- REACH Uyumluluk Kodu
- not_compliant
- Bushing Length
- 0.25 inch
- Sealing
- EPOXY
