Specifications
- Actuator Material
- Brass, Chrome Plated
- Switch Function
- On-Off-On
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC 3A DC
- Contact Ac Max Rating R Load
- 3A@250VAC
- Bushing Thread
- Unthreaded
- Contact Currentacmax
- 3A
- End Contact Material
- SILVER ALLOY
- Ambalaj
- Bulk
- Dielectric Withstanding Voltage
- 1500VAC V
- Seri
- M2
- Contact Voltageacmax
- 250V
- Özellikler
- Process Sealed
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- GLASS FILLED POLYAMIDE
- Actuator Length
- 12.70mm
- Length Termination
- 0.232 inch
- Kurşunsuz Kodu
- yes
- Body Length Or Diameter
- 12.7mm
- Center Contact Plating
- SILVER
- Parça Durumu
- Obsolete
- Çalışma Sıcaklığı
- -30°C~85°C
- Illumination
- Non-Illuminated
- Fabrika Tedarik Süresi
- 8 Weeks
- Electricallife
- 25,000 Cycles
- Yayın Yılı
- 2012
- Pcb Hole Count
- 3
- Montaj
- Through Hole
- Voltage Rated Ac
- 125V
- End Contact Plating
- SILVER
- Terminal
- PC Pin
- Circuit
- SPDT
- Body Height
- 9.398mm
- Body Breadth
- 6.604 mm
- Montaj Tipi
- Through Hole
- Sealing
- EPOXY
- Actuator Type
- Standard Round
- Actuator Finish
- NICKEL
- Bushing Length
- 0.25 inch
