Volume pricing
- 1+ pcs$7.58
- 10+ pcs$7.15
- 100+ pcs$6.75
- 500+ pcs$6.37
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 8 Weeks
- Circuit
- SPDT
- Özellikler
- Process Sealed
- Body Length Or Diameter
- 12.7mm
- Body Height
- 30.5816mm
- Montaj Tipi
- Through Hole
- Contact Plating
- Gold
- Switch Function
- On-Mom
- Voltage Rated Dc
- 28V
- Tip
- Standard
- Pcb Hole Count
- 3
- Color Actuatorcap
- Black
- Montaj
- Through Hole
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Actuator Material
- BRASS
- Contact Resistance
- 0.03mOhm
- Kurşunsuz Kodu
- yes
- Actuator Travel
- 0.9906 mm
- Seri
- M2
- Contact Function
- ON-(ON)
- Voltage Rated Ac
- 28V
- End Contact Material
- COPPER
- Terminal Material
- BRASS
- Body Breadth
- 6.604 mm
- Ambalaj
- Bulk
- Yayın Yılı
- 2011
- Electricallife
- 100,000 Cycles
- Sealing
- EPOXY
- Length Termination
- 0.189 inch
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 0.4VA AC/DC
- Terminal Stili
- PC Pin
- Çalışma Sıcaklığı
- -30°C~85°C
- Bushing Diameter
- 0.244 inch
- Mechanical Life
- 200,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Bushing Length
- 0.25 inch
- REACH Uyumluluk Kodu
- not_compliant
- ECCN Kodu
- EAR99
- Dielectric Withstanding Voltage
- 1000VAC V
