Volume pricing
- 1+ pcs$8.44
- 10+ pcs$7.96
- 100+ pcs$7.51
- 500+ pcs$7.08
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Length Termination
- 0.189 inch
- Sealing
- EPOXY
- Electricallife
- 100,000 Cycles
- Yayın Yılı
- 2011
- Orientation
- Vertical
- Ambalaj
- Tray
- RoHS Durumu
- ROHS3 Compliant
- Mechanical Life
- 200,000 Cycles
- Çalışma Sıcaklığı
- -30°C~85°C
- Bushing Diameter
- 0.244 inch
- Terminal Stili
- PC Pin
- Current Rating Amps
- 0.4VA AC/DC
- Insulation Resistance
- 1000000000Ohm
- Dielectric Withstanding Voltage
- 1000VAC V
- ECCN Kodu
- EAR99
- Bushing Length
- 0.25 inch
- REACH Uyumluluk Kodu
- not_compliant
- Parça Durumu
- Active
- Solderability
- WAVE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e4
- Power Rating
- 400mW
- Center Contact Material
- COPPER
- Terminal
- PC Pin
- Actuator Type
- Round, Button
- Akım Değeri
- 1A
- Actuator Length
- 0.307 inch
- Contact Plating
- Gold
- Body Height
- 30.3784mm
- Montaj Tipi
- Through Hole
- Özellikler
- Process Sealed
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 8 Weeks
- Body Length Or Diameter
- 12.7mm
- Tip
- Standard
- Pcb Hole Count
- 3
- Color Actuatorcap
- Black
- Switch Function
- On-Mom
- Voltage Rated Dc
- 28V
- Contact Resistance
- 0.03mOhm
