Specifications
- Bushing Length
- 0.25 inch
- REACH Uyumluluk Kodu
- not_compliant
- ECCN Kodu
- EAR99
- Dielectric Withstanding Voltage
- 1000VAC V
- Actuator Length
- 0.282 inch
- Akım Değeri
- 1A
- Power Rating
- 400mW
- Terminal
- PC Pin
- Actuator Type
- Round, Button
- JESD-609 Kodu
- e4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Solderability
- WAVE
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Yayın Yılı
- 2011
- Electricallife
- 25,000 Cycles
- Sealing
- EPOXY
- Length Termination
- 0.189 inch
- Current Rating Amps
- 1A AC/DC
- Insulation Resistance
- 1000000000Ohm
- Terminal Stili
- PC Pin
- Bushing Diameter
- 0.244 inch
- Çalışma Sıcaklığı
- -30°C~85°C
- Mechanical Life
- 200,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Through Hole
- Kılıf / Paket
- 201
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Actuator Material
- BRASS
- Contact Resistance
- 0.02mOhm
- Kurşunsuz Kodu
- yes
- Contact Ac Max Rating R Load
- 1A@125VAC
- Actuator Travel
- 0.9906 mm
- Seri
- M2
- Contact Function
- ON-(ON)
- Voltage Rated Ac
- 125V
- Terminal Material
- BRASS
- Body Breadth
- 8.001 mm
- Fabrika Tedarik Süresi
- 14 Weeks
- Circuit
- SPDT
