Volume pricing
- 1+ pcs$8.26
- 10+ pcs$7.79
- 100+ pcs$7.35
- 500+ pcs$6.94
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 28V
- Switch Function
- On-Mom
- Color Actuatorcap
- Black
- Pcb Hole Count
- 3
- Tip
- Standard
- Body Length Or Diameter
- 12.7mm
- Fabrika Tedarik Süresi
- 9 Weeks
- Circuit
- SPDT
- Özellikler
- Process Sealed
- Montaj Tipi
- Through Hole
- Body Height
- 29.6418mm
- Contact Plating
- Gold
- Seri
- M2
- Contact Function
- ON-(ON)
- Voltage Rated Ac
- 28V
- Actuator Travel
- 0.9906 mm
- End Contact Material
- COPPER
- Terminal Material
- BRASS
- Body Breadth
- 6.604 mm
- Montaj
- Through Hole
- Actuator Material
- BRASS
- Kurşunsuz
- Lead Free
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.03mOhm
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 0.4VA AC/DC
- Terminal Stili
- PC Pin
- Bushing Diameter
- 0.244 inch
- Çalışma Sıcaklığı
- -30°C~85°C
- RoHS Durumu
- ROHS3 Compliant
- Mechanical Life
- 200,000 Cycles
- Ambalaj
- Tray
- Orientation
- Vertical
- Yayın Yılı
- 2011
- Electricallife
- 100,000 Cycles
- Sealing
- EPOXY
- Length Termination
- 0.189 inch
- Actuator Length
- 0.282 inch
- Akım Değeri
- 1A
