Specifications
- Illumination Type
- Illuminated, Non-Illuminated
- Dielectric Withstanding Voltage
- 1500VAC V
- Reach Svhc
- No SVHC
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Contact Current Rating
- 6A
- Actuator Type
- Standard Round
- Contact Currentacmax
- 3A
- Çalışma Sıcaklığı
- -30°C~85°C
- Housing Material
- STAINLESS STEEL
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 9 Weeks
- Sealing
- EPOXY
- Switch Function
- On-On-On
- Switch Type
- TOGGLE SWITCH
- Kurşunsuz
- Lead Free
- Contact Voltageacmax
- 250V
- Contact Ac Max Rating R Load
- 3A@250VAC
- Bushing Length
- 0.35 inch
- Orientation
- Vertical
- Özellikler
- Jumper needed to achieve triple throw
- Kurşunsuz Kodu
- yes
- Circuit
- DP3T
- Terminal Material
- COPPER ALLOY
- Actuator Material
- Brass, Chrome Plated
- Voltage Rated Dc
- 30V
- Ambalaj
- Bulk
- Seri
- M
- Solderability
- WAVE
- Yayın Yılı
- 2012
- HTS Kodu
- 8536.50.90.65
- Voltage Rated Ac
- 125V
- Actuator Length
- 10.50mm
- Parça Durumu
- Active
- Insulation Materials
- DIALLYL PHTHALATE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Panel Mount
- Terminal
- PC Pin
- JESD-609 Kodu
- e4
- Insulation Resistance
- 1000000000Ohm
- Length Termination
- 0.25 inch
