Specifications
- Current Rating Amps
- 6A AC 3A DC
- Electricallife
- 25,000 Cycles
- Contact Ac Max Rating R Load
- 3A@250VAC
- Bushing Length
- 0.35 inch
- Illumination
- Non-Illuminated
- Özellikler
- Jumper needed to achieve triple throw
- Contact Voltageacmax
- 250V
- Montaj Tipi
- Panel Mount
- Terminal
- Solder
- JESD-609 Kodu
- e4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Length Termination
- 0.157 inch
- Akım Değeri
- 3A
- Insulation Resistance
- 1000000000Ohm
- Actuator Material
- Brass, Chrome Plated
- Terminal Material
- COPPER ALLOY
- Montaj
- Panel
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Bushing Thread
- 1/4-40
- Voltage Rated Dc
- 30V
- Kurşunsuz Kodu
- yes
- Circuit
- DP3T
- Contact Plating
- Silver
- Terminal Stili
- Solder Lug
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Yayın Yılı
- 2012
- Additional Feature
- SPLASHPROOF BUSHING
- Actuator Type
- Standard Round
- Voltage Rated Ac
- 125V
- Ratings
- Dust Tight, IP67, Waterproof
- Ambalaj
- Bulk
- Seri
- M
- Solderability
- WAVE
- Dielectric Withstanding Voltage
- 1500VAC V
- Fabrika Tedarik Süresi
- 10 Weeks
- Sealing
- EPOXY
- Parça Durumu
- Active
- Switch Type
- TOGGLE SWITCH
- Insulation Materials
- DIALLYL PHTHALATE
- Switch Function
- On-On-On
