Specifications
- Max Voltage Rating Dc
- 30V
- Terminal Stili
- Solder Lug
- Max Current Rating
- 6A
- Contact Materials
- Silver
- Max Voltage Rating Ac
- 250V
- Circuit
- 4PDT
- Kurşunsuz Kodu
- yes
- Depth
- 22.3mm
- Bushing Thread
- 1/4-40
- Voltage Rated Dc
- 30V
- Montaj
- Panel
- Terminal Material
- COPPER ALLOY
- Actuator Material
- Brass, Chrome Plated
- Insulation Resistance
- 1000000000Ohm
- Akım Değeri
- 3A
- Kurşunsuz
- Lead Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- JESD-609 Kodu
- e4
- Montaj Tipi
- Panel Mount
- Orientation
- Vertical
- Özellikler
- Epoxy Sealed Terminals
- Illumination
- Non-Illuminated
- Contact Ac Max Rating R Load
- 3A@250VAC
- Electricallife
- 25,000 Cycles
- Current Rating Amps
- 6A AC 3A DC
- Çalışma Sıcaklığı
- -30°C~85°C
- Life Cycles
- 25000 cycles
- Contact Currentacmax
- 3A
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- STAINLESS STEEL
- Actuator Length
- 11.40mm
- Switch Function
- On-Off-On
- Insulation Materials
- DIALLYL PHTHALATE
- Switch Type
- TOGGLE SWITCH
- Parça Durumu
- Active
- Genişlik
- 13mm
- Dielectric Withstanding Voltage
- 1500VAC V
- Solderability
- WAVE
- Seri
- M
