Specifications
- Seri
- M
- Terminal
- Solder
- Illumination
- Non-Illuminated
- Insulation Resistance
- 1000000000Ohm
- Housing Material
- STAINLESS STEEL
- JESD-609 Kodu
- e4
- Voltage Rated Ac
- 125V
- Dielectric Withstanding Voltage
- 1500VAC V
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Terminal Kaplaması
- GOLD OVER NICKEL/SILVER
- Insulation Materials
- DIALLYL PHTHALATE
- Akım Değeri
- 3A
- Bushing Thread
- 1/4-40
- Center Contact Plating
- SILVER
- Current Rating Amps
- 6A AC 3A DC
- Fabrika Tedarik Süresi
- 10 Weeks
- Bushing Length
- 0.35 inch
- End Contact Plating
- SILVER
- Additional Feature
- SPLASHPROOF BUSHING
- End Contact Material
- SILVER
- Voltage Rated Dc
- 30V
- Circuit
- DPDT
- Çalışma Sıcaklığı
- -30°C~85°C
- Contact Voltageacmax
- 250V
- Terminal Stili
- Solder Lug
- Montaj
- Panel
- Contact Function
- ON-OFF-(ON)
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Solderability
- WAVE
- Actuator Length
- 10.50mm
- Switch Type
- TOGGLE SWITCH
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Özellikler
- Epoxy Sealed Terminals
- Contact Currentacmax
- 3A
- Terminal Material
- COPPER ALLOY
- Center Contact Material
- SILVER
- Actuator Type
- Standard Round
- Length Termination
- 0.157 inch
