Specifications
- Circuit
- SP3T
- Insulation Materials
- DIALLYL PHTHALATE
- Electricallife
- 50,000 Cycles
- Max Voltage Rating Dc
- 28V
- RoHS Durumu
- ROHS3 Compliant
- Voltage Rated Ac
- 28V
- Bushing Thread
- Unthreaded
- Switch Type
- TOGGLE SWITCH
- Switch Function
- On-On-On
- Çalışma Sıcaklığı
- -30°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Ac
- 28V
- Parça Durumu
- Active
- Yayın Yılı
- 2015
- Terminal
- PC Pin
- Contact Materials
- Copper
- Voltage Rated Dc
- 28V
- Solderability
- WAVE
- Ambalaj
- Bulk
- Actuator Material
- Brass, Chrome Plated
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Fabrika Tedarik Süresi
- 19 Weeks
- Illumination
- Non-Illuminated
- Montaj
- Through Hole, Vertical
- Contact Plating
- Gold
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Current Rating Amps
- 0.4VA AC/DC
- JESD-609 Kodu
- e4
- Terminal Stili
- PC Pin
- Özellikler
- Jumper needed to achieve triple throw
- Uzunluk
- 8mm
- Actuator Length
- 6.86mm
- Max Current Rating
- 100mA
- Actuator Type
- Standard Round
- Seri
- M
- Dielectric Withstanding Voltage
- 1500VAC V
- Housing Material
- STAINLESS STEEL
- Sealing
- EPOXY
- Depth
- 34.88mm
- Pcb Hole Count
- 8
