Volume pricing
- 1+ pcs$10.37
- 10+ pcs$9.78
- 100+ pcs$9.23
- 500+ pcs$8.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- STAINLESS STEEL
- Dielectric Withstanding Voltage
- 1500VAC V
- Actuator Type
- Standard Round
- Contact Ac Max Rating R Load
- 3A@250VAC
- Seri
- M
- Bushing Length
- 0.472 inch
- Akım Değeri
- 3A
- Length Termination
- 0.25 inch
- Kurşunsuz Kodu
- yes
- Insulation Resistance
- 1000000000Ohm
- Pcb Hole Count
- 6
- Sealing
- EPOXY
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Terminal Stili
- PC Pin
- JESD-609 Kodu
- e4
- Current Rating Amps
- 6A AC 3A DC
- Terminal Material
- COPPER ALLOY
- Montaj Tipi
- Panel Mount
- Actuator Length
- 11.50mm
- Özellikler
- Jumper needed to achieve triple throw
- End Contact Plating
- SILVER
- Terminal
- PC Pin
- End Contact Material
- SILVER
- Terminal Kaplaması
- GOLD OVER NICKEL/SILVER
- Yayın Yılı
- 2012
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -30°C~85°C
- Montaj
- Panel
- Illumination
- Non-Illuminated
- Fabrika Tedarik Süresi
- 10 Weeks
- Actuator Material
- Brass, Chrome Plated
- Ambalaj
- Bulk
- Solderability
- WAVE
- Voltage Rated Dc
- 30V
- Contact Currentacmax
- 3A
- RoHS Durumu
- ROHS3 Compliant
- Center Contact Material
- SILVER
- Contact Voltageacmax
- 250V
- Electricallife
- 25,000 Cycles
