Specifications
- Max Voltage Rating Ac
- 28V
- Yayın Yılı
- 2012
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -30°C~85°C
- Contact Materials
- Copper
- Terminal
- Solder
- Actuator Material
- Polyamide
- Ambalaj
- Tray
- Voltage Rated Dc
- 28V
- Montaj
- Panel, Snap in
- Fabrika Tedarik Süresi
- 10 Weeks
- Electricallife
- 50,000 Cycles
- Max Voltage Rating Dc
- 28V
- Circuit
- DPDT
- Actuator Angle
- 25 deg
- Mechanical Life
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Power Rating
- 400mW
- Voltage Rated Ac
- 28V
- Switch Type
- ROCKER SWITCH
- Switch Function
- On-On
- Actuator Marking
- No Marking
- Dielectric Withstanding Voltage
- 1500VAC V
- Housing Material
- DIALLYL PHTHALATE
- Max Current Rating
- 100mA
- Actuator Type
- Concave (Standard V)
- Seri
- M
- Depth
- 15.6mm
- Insulation Resistance
- 1000000000Ohm
- Panel Cutout Dimensions
- Rectangular - 15.90mm x 13.10mm
- Kurşunsuz Kodu
- yes
- Color Actuatorcap
- Black
- Kurşunsuz
- Lead Free
- Orientation
- Vertical
- Contact Plating
- Gold
- Current Rating Amps
- 0.4VA AC/DC
- Terminal Stili
- Solder Lug
- Montaj Tipi
- Panel Mount, Snap-In
- Özellikler
- Epoxy Sealed Terminals
