Specifications
- Terminal Stili
- PC Pin
- JESD-609 Kodu
- e4
- Current Rating Amps
- 6A AC 4A DC
- Kurşunsuz
- Contains Lead
- Illumination Type
- Illuminated, Non-Illuminated
- Dielectric Withstanding Voltage
- 1500VAC V
- Seri
- M
- Contact Ac Max Rating R Load
- 3A@250VAC
- Max Current Rating
- 6A
- Akım Değeri
- 4A
- RoHS Durumu
- ROHS3 Compliant
- Electricallife
- 25,000 Cycles
- Circuit
- DPDT
- Switch Type
- TOGGLE SWITCH
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.50.90.65
- Terminal
- PC Pin
- Contact Materials
- Silver
- Yayın Yılı
- 2015
- Max Voltage Rating Ac
- 250V
- Reach Svhc
- No SVHC
- Terminal Material
- COPPER ALLOY
- Montaj Tipi
- Through Hole
- Actuator Length
- 10.50mm
- Uzunluk
- 16.3mm
- Özellikler
- Epoxy Sealed Terminals
- Housing Material
- STAINLESS STEEL
- Actuator Type
- Standard Round
- Kurşunsuz Kodu
- yes
- Insulation Resistance
- 1000000000Ohm
- Depth
- 12.7mm
- Pcb Hole Count
- 10
- Contact Currentacmax
- 3A
- Max Voltage Rating Dc
- 30V
- Insulation Materials
- DIALLYL PHTHALATE
- Switch Function
- On-On
- Bushing Thread
- Unthreaded
- Voltage Rated Ac
- 125V
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -30°C~85°C
