Specifications
- Contact Materials
- Copper
- Contact Function
- ON-OFF-(ON)
- Voltage Rated Ac
- 28V
- Actuator Type
- Standard Round
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Switch Function
- On-Off-Mom
- Parça Durumu
- Active
- Illumination
- Non-Illuminated
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Fabrika Tedarik Süresi
- 10 Weeks
- Electricallife
- 50,000 Cycles
- Orientation
- Vertical
- Actuator Length
- 10.50mm
- Dielectric Withstanding Voltage
- 1500VAC V
- Contact Plating
- Gold
- Actuator Material
- Brass, Chrome Plated
- Terminal Stili
- Solder Lug
- Uzunluk
- 13mm
- Voltage Rated Dc
- 28V
- Çalışma Sıcaklığı
- -30°C~85°C
- Genişlik
- 7.9mm
- Kurşunsuz
- Lead Free
- Depth
- 8mm
- Circuit
- SPDT
- Özellikler
- Epoxy Sealed Terminals
- Montaj
- Panel
- Switch Type
- TOGGLE SWITCH
- Max Current Rating
- 100mA
- Max Voltage Rating Ac
- 28V
- Bushing Thread
- 1/4-40
- Seri
- M
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Dc
- 28V
- Insulation Resistance
- 1000000000Ohm
- Ambalaj
- Bulk
- Yayın Yılı
- 2006
- Current Rating Amps
- 0.4VA AC/DC
- Montaj Tipi
- Panel Mount
- Kurşunsuz Kodu
- yes
