Specifications
- Yayın Yılı
- 2015
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Type
- TOGGLE SWITCH
- Insulation Resistance
- 1000000000Ohm
- Operating Forcemax
- 3.92 N
- Kurşunsuz Kodu
- yes
- Solderability
- WAVE
- Illumination Type
- Illuminated, Non-Illuminated
- Depth
- 39.33mm
- Housing Material
- STAINLESS STEEL
- Actuator Length
- 16.50mm
- Pcb Hole Count
- 5
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Circuit
- SPDT
- Ambalaj
- Tray
- Uzunluk
- 13mm
- Bushing Thread
- Unthreaded
- Actuator Material
- Brass, Chrome Plated
- Çalışma Sıcaklığı
- -30°C~85°C
- Voltage Rated Dc
- 28V
- Current Rating Amps
- 0.4VA AC/DC
- Parça Durumu
- Active
- Insulation Materials
- DIALLYL PHTHALATE
- JESD-609 Kodu
- e4
- Max Voltage Rating Dc
- 28V
- Terminal Stili
- PC Pin
- Contact Materials
- Copper
- Montaj
- Through Hole
- Contact Ac Max Rating R Load
- .014A@28VAC
- Dielectric Withstanding Voltage
- 1500VAC V
- Contact Currentdcmax
- 0.014A
- Actuator Type
- Locking Lever
- Actuator Finish
- NICKEL
- Montaj Tipi
- Through Hole, Right Angle
- Electricallife
- 50,000 Cycles
- Contact Currentacmax
- 0.014A
- Contact Current Rating
- 100mA
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Epoxy Sealed Terminals
- ECCN Kodu
- EAR99
