Volume pricing
- 1+ pcs$5.77
- 10+ pcs$5.45
- 100+ pcs$5.14
- 500+ pcs$4.85
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Uzunluk
- 13mm
- Actuator Type
- Standard Round
- Montaj
- Bushing, Panel
- Bushing Thread
- 1/4-40
- Illumination Type
- Illuminated, Non-Illuminated
- Contact Materials
- Silver
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Length
- 10.50mm
- Insulation Materials
- DIALLYL PHTHALATE
- Switch Function
- On-On
- Ratings
- Dust Tight, IP67, Waterproof
- Contact Currentacmax
- 3A
- Depth
- 10mm
- Contact Ac Max Rating R Load
- 3A@250VAC
- Akım Değeri
- 4A
- Additional Feature
- SPLASHPROOF BUSHING
- Switch Type
- TOGGLE SWITCH
- Insulation Resistance
- 1000000000Ohm
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Terminal
- Solder
- Reach Svhc
- No SVHC
- Ambalaj
- Bulk
- Max Voltage Rating Ac
- 250V
- Contact Current Rating
- 6A
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Housing Material
- STAINLESS STEEL
- Electricallife
- 25,000 Cycles
- Voltage Rated Ac
- 125V
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Epoxy Sealed Terminals
- Orientation
- Vertical
- Çalışma Sıcaklığı
- -30°C~85°C
- Max Current Rating
- 6A
- Voltage Rated Dc
- 30V
- Dielectric Withstanding Voltage
- 1500VAC V
- Max Voltage Rating Dc
- 30V
- Terminal Material
- COPPER ALLOY
- Current Rating Amps
- 6A AC 4A DC
