Specifications
- Panel Cutout Dimensions
- Circular - 6.50mm Dia
- Max Voltage Rating Ac
- 250V
- Contact Current Rating
- 6A
- Housing Material
- STAINLESS STEEL
- Electricallife
- 25,000 Cycles
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Epoxy Sealed Terminals
- Voltage Rated Ac
- 125V
- Çalışma Sıcaklığı
- -30°C~85°C
- Max Current Rating
- 6A
- Dielectric Withstanding Voltage
- 1500VAC V
- Voltage Rated Dc
- 30V
- Max Voltage Rating Dc
- 30V
- Terminal Material
- COPPER ALLOY
- Current Rating Amps
- 6A AC 4A DC
- Seri
- M
- Illumination
- Non-Illuminated
- Solderability
- WAVE
- HTS Kodu
- 8536.50.90.65
- Fabrika Tedarik Süresi
- 9 Weeks
- Actuator Material
- Brass, Chrome Plated
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Panel Mount
- Circuit
- SPST
- Parça Durumu
- Active
- Terminal Stili
- Solder Lug
- JESD-609 Kodu
- e4
- ECCN Kodu
- EAR99
- Uzunluk
- 13mm
- Actuator Type
- Standard Round
- Yayın Yılı
- 2012
- Montaj
- Panel
- Bushing Thread
- 1/4-40
- Illumination Type
- Illuminated, Non-Illuminated
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Silver
- Actuator Length
- 10.50mm
- Insulation Materials
- DIALLYL PHTHALATE
- Switch Function
- On-Off
